Red HeadPlay HD 1280x800 FPV Goggles 32Ch 5.8GHz Headset Receiver for DJI

Description

Features: 1280x800px HD gloss screen. Integrated 5.8GHz receiver. 32 channel receiver designed by RangeVideo. HDMI input. External AV input. Fully adjustable picture via intuitive menus Control via button panel (distinct button design for "blind" operation) Rugged design with extremely durable materials Different density foam pads allow you to adapt the goggles to your needs. Easy to clean optics Electrical Properties HDMI type C (HDMI-in) XS9JK (latched high end connector): Power Supply, Video-in, Audio-in, Ground, 5V out SMA antenna connector 32 channel 5.8GHz A/V receiver 8 segment display Built-in speaker with volume control on buttons Reverse voltage protection Specifications: Main Color: Red Screen resolution: 1280x800 Field of View: 72 degree Sensitivity: -90dBm Frequencies (MHz): Band 1: 5725, 5745, 5765, 5785, 5805, 5825, 5845, 5865 Band 2: 5733, 5752, 5771, 5790, 5809, 5828, 5847, 5866 Band 3: 5705, 5685, 5665, 5645, 5885, 5905, 5925, 5945 Band 4: 5740, 5760, 5780, 5800, 5820, 5840, 5860, 5880 Current consumption 340mA@12V LiPo Battery Supply voltage: 2S/7.4V 1000MAH Package Including: 1 x Goggle 1 x AV Cable 1 x Battery charger with 3 plugs 1 x 1000mah battery 1 x lens 1 x antenna Notes: Keep your Headplay HDs free from dust. Try to avoid touching the optics. Clean the Headplay HDs with compressed air only. Avoid using cleaning cloth. Do not use any chemicals to clean your set and/or optics.It is the second generation FPV Goggles,which is not difference from the first generation
